Models |
|
![](images/BPN-DE110SS_front.png) BPN-DE110SS 1x5.25" to 1x3.5" SATA/SAS 6.0 Gb/s Trayless Hot-Swap Cage |
|
![](images/BPN-DE230SS_front.png) BPN-DE230SS 2x5.25" to 3x3.5" SAS/SATA 6.0 Gb/s Trayless Hot-Swap Cage |
|
![](images/BPN-DE340SS_front.png) BPN-DE340SS 3x5.25" to 4x3.5" SAS/SATA 6.0 Gb/s Trayless Hot-Swap Cage |
|
![](images/BPN-DE350SS_front.png) BPN-DE350SS 3x5.25" to 5x3.5" SAS/SATA 6.0 Gb/s Trayless Hot-Swap Cage |
|
Dimensions (WxHxD) |
5.75" x 1.65" x 7.10" 146.1 mm x 41.9 mm x 180.3 mm |
5.71" x 3.35" x 7.64" 145.0 mm x 85.1 mm x 194.1 mm |
5.71" x 4.92" x 7.79" 145.0 mm x 125.0 mm x 197.9 mm |
5.71" x 4.92" x 7.79" 145.0 mm x 125.0 mm x 197.9 mm |
|
Standard Drive Bays |
5.25" Drives: 1 3.5" Hotswap: 1 |
5.25" Drives: 2 3.5" Hotswap: 3 |
5.25" Drives: 3 3.5" Hotswap: 4 |
5.25" Drives: 3 Hotswap 3.5: 5 |
|
Hotswap HDD Type |
![](images/BPN-DE_hdd.png) |
|
Security |
![](images/BPN-DE_keylock.png) |
|
Indicators |
Blue for Power on / Purple for HDD Access |
|
Material of Handle |
Aluminum |
|
Material of Main Chassis |
Aluminum |
|
Material of Front Bezel |
Aluminum |
|
Color of Main Chassis |
Black |
|
Color of Front Bezel |
![](images/BPN-DE_bezels.png) |
|
Cooling Fan |
1x40mm Optional Fan
![](images/BPN-DE110SS_fan.png) |
|
1x70mm Cooling Fan
![](images/BPN-DE230SS_fan.png) |
|
1x80mm Cooling Fan
![](images/BPN-DE340SS_fan.png) |
|
1x80mm Cooling Fan
![](images/BPN-DE350SS_fan.png) |
|
Ordering Information (Part Number) |
Black Handle: BPN-DE110SS-BLACK
Blue Handle: BPN-DE110SS-BLUE
Red Handle: BPN-DE110SS-RED
Silver Handle: BPN-DE110SS-SILVER |
Black Handle: BPN-DE230SS-BLACK
Blue Handle: BPN-DE230SS-BLUE
Red Handle: BPN-DE230SS-RED
Silver Handle: BPN-DE230SS-SILVER |
Black Handle: BPN-DE340SS-BLACK
Blue Handle: BPN-DE340SS-BLUE
Red Handle: BPN-DE340SS-RED
Silver Handle: BPN-DE340SS-SILVER |
Black Handle:BPN-DE350SS-BLACK
Blue Handle:BPN-DE350SS-BLUE
Red Handle:BPN-DE350SS-RED
Silver Handle:BPN-DE350SS-SILVER |
|
Package Content |
![](images/BPN-DE110SS_pkg.png) SATA Cable Included (1pcs) |
![](images/BPN-DE230SS_pkg.png) SATA Cable Included (3pcs) |
![](images/BPN-DE340SS_pkg.png) SATA Cable Included (4pcs) |
![](images/BPN-DE350SS_pkg.png) SATA Cable Included (5pcs) |
|
