FS-1020
Fanless Desktop for Mini-ITX
Fanless Desktop for Mini-ITX
Features
| Product Specifications | |
| Model Number | FS-1020 |
| RoHS Compliance | Yes |
| Standard Drive Bays |
Internal Drive Bay : 2.5" HDD x 2. |
| Front Panel | Power SW x1 + Power LED x1 + HDD LCD x1 USB Port x 2 (USB3.0 optional). |
| Back Panel | Standard I/O shield. Expansion PCI/PCI-E slot x 3. |
| Form Factor: | 3U |
| Motherboard Size: | For Mini-ITX |
| External Adapter Input | ADAPTER 120W/19V x1 + C4(19-24Vdc 150W) Converter x 1 |
| Dimensions (WxHxD) | 16.90" x 5.10" x 10.40" 429.3 mm x 129.5 mm x 264.2 mm |
| Images | Model # | Motherboard Size | Company Name | Processor family | Compatible processor |
 |
SBC-230 | 3.5" SBC (5.8-in x 4.0-in) | asrock | Intel Apollo Lake | E3940 N4200 N3350 |
 |
SBC-E230 | 3.5" SBC (5.8-in x 4.0-in) | asrock | Intel Apollo Lake | E3940 N4200 N3350 |
 |
SBC-E230-WT | 3.5" SBC (5.8-in x 4.0-in) | asrock | Intel Apollo Lake | E3940 N4200 N3350 |
 |
SBC-220 | 3.5" SBC (5.8-in x 4.0-in) | asrock | Intel Braswell | N3160 N3150 |
 |
SBC-210 | 3.5" SBC (5.8-in x 4.0-in) | asrock | Intel Baytrail | E3845 E3826 J1900 N2930 N2920 |
 |
SBC-211 | 3.5" SBC (5.8-in x 4.0-in) | asrock | Intel Baytrail | E3845 E3826 J1900 N2930 N2920 |
 |
SBC-212-WT | 3.5" SBC (5.8-in x 4.0-in) | asrock | Intel Baytrail | E3845 E3826 J1900 N2930 N2920 |
 |
IMB 156 | Mini-ITX (6.7-in x 6.7-in) | asrock | Intel Apollo Lake | E3940 N4200 N3350 |
 |
IMB E156 | Mini-ITX (6.7-in x 6.7-in) | asrock | Intel Apollo Lake | E3940 N4200 N3350 |
 |
IMB 157 | Mini-ITX (6.7-in x 6.7-in) | asrock | Intel Apollo Lake | E3940 N4200 N3350 |
 |
IMB 154 | Mini-ITX (6.7-in x 6.7-in) | asrock | Intel Braswell | N3160 N3150 |
 |
IMB 150 | Mini-ITX (6.7-in x 6.7-in) | asrock | Intel Baytrail | J1900 N2930 N2920 |
 |
IMB 151 | Mini-ITX (6.7-in x 6.7-in) | asrock | Intel Baytrail | J1900 N2930 N2920 |
 |
IMB 152 | Mini-ITX (6.7-in x 6.7-in) | asrock | Intel Baytrail | J1900 N2930 N2920 |
 |
IMB 153 | Mini-ITX (6.7-in x 6.7-in) | asrock | Intel Baytrail | J1900 N2930 N2920 |
 |
IMB 180 | Mini-ITX (6.7-in x 6.7-in) | asrock | QM87 | Intel Core i7-4930MQ Intel Core i7-4702MQ Intel Core i5-4330M Intel Core i5-4200M Intel Core i3- |
 |
IMB 182 | Mini-ITX (6.7-in x 6.7-in) | asrock | QM87 | Intel Core i7-4930MQ Intel Core i7-4702MQ Intel Core i5-4330M Intel Core i5-4200M Intel Core i3- |
 |
IMB 170 | Mini-ITX (6.7-in x 6.7-in) | asrock | QM77 | Intel Core i7-3610QE Intel Core i5-3610ME Intel Core i3-3120ME Intel Core i7-2710QE Intel Core i |
