FS-P107
7.1" Panel PC chassis for SBC system with Projected Capacitive Type Touch Screen
Features
  • For 3.5"SBC with CPU TDP 10W max.
  • IP65 front bezel
  • 7.1"panel with touch
  • Silent, and dust-free
Product Specifications
Model NumberFS-P107
RoHS ComplianceYes
Standard Drive Bays None
Material SGCC / Anodized aluminum heatsink
SurfaceBlack wet Surface paint with texture coat.
LCDResolution: 1024 RGB (H) 600(V)
Brightness: 320cd/m2 (typ.)
Color Support: 16.7M
Contrast Ratio: 500:1 (typ.)
Response Time: 20ms (typ.)
TouchTouchscreen Type: Projected Capacitive
Surface Hardness: ò6H
Durability: 100,000,000 times
Transparency: ò90%
TDPMax. 10W
External AC Adapter60W: Input (AC 100~240V);
Output (DC 12V@5A)
External AC Adapter80W: Input (AC 100~240V);
Output (DC 12V@6.67A)
Dimensions (WxHxD)7.64" x 2.02" x 5.20"
194.1 mm x 51.3 mm x 132.1 mm
