FS-P117
17" Panel PC chassis for mini-ITX system with Projected Capacitive Type Touch Screen
Features
  • For MINI-ITX with CPU TDP 37W max.
  • IP65 front bezel
  • 17" panel with touch
  • Silent, and dust-free
Product Specifications
Model NumberFS-P117
RoHS ComplianceYes
Standard Drive Bays None
Material SGCC / Anodized aluminum heatsink
SurfaceBlack wet Surface paint with texture coat.
LCDResolution: 1280xRGBx1024
Brightness: 250cd/m2 (typ.)
Color Support: 16.7M/262k
Contrast Ratio: 1000:1 (typ.)
Response Time: 5ms (typ.)
TouchTouchscreen Type: Projected Capacitive
Surface Hardness: ò7H
Durability: 100,000,000 times
Transparency: ò90%
TDPMax. 37W
Storage2.5" HDD x 1
Power Solution Option 1
Internal DC Power BoardC7 (80W) DC Power Board
External AC Adapter60W: Input (AC 100~240V);
Output (DC 12V@5A)
Power Solution Option 2
Internal DC Power BoardC7 (80W) DC Power Board
External AC Adapter80W: Input (AC 100~240V);
Output (DC 12V@6.67A)
Power Solution Option 3
Internal DC Power BoardC4 (150W, 19V~24V) DC Power Board
External AC Adapter90W: Input (AC 100~240V);
Output (DC 19V@4.74A)
Power Solution Option 4
Internal DC Power BoardC4 (150W, 19V~24V) DC Power Board
External AC Adapter120W: Input (AC 100~240V);
Output (DC 19V@6.32A)
Dimensions (WxHxD)16.80" x 2.15" x 14.10"
426.7 mm x 54.6 mm x 358.1 mm
