D-200SEA-SL-T7SA
2U Compact Stylish Rackmount Chassis with silver SEA Bezel and Rugged 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack

Patented Aluminum Front Panel with Locks,Taiwan: 200281 / 190240 , China: 2L01259648.5
Front Access USB2.0 x2
80mm x1 cooling fan
Power and HDD LED
Power and Alarm Reset Switch
Optional Aluminum Chassis
With rugged 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack

Product Introduction
The 2U compact industrial rackmount chassis D Storm D-200SEA-SL-T7SA. The full size I/O supports all ATX motherboard. Combine hot-swappable cage for RAID configuration, and total up to 4 drive storage capacity. D-200SEA-SL-T7SA support 3 add-on cards include PCI, PCI-X, AGP, or PCI-Express architecture that provide your server or cluster maximum flexibility and performance. Optional Aluminum Body reduces total chassis weight and also provides enhanced thermal cooling solution, also with rugged 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack

Specifications	Download	FAQ
Optional Accessories	Compatible Power Supplies	Compatible Motherboards
Riser Card Info

Model Number	D-200SEA-SL-T7SA
RoHS Compliance	Yes
Form factor	2 U
Standard Drive Bays	3.5" Drives: 2 5.25" Drives: 2
Indicators	Power, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 )
Switches	Power, Reset
Supported PSU Type	2U
Expansion Slots	3
Security	Front Bezel Key Lock
Material of Front Bezel	Aluminum alloy
Material of Handle	SECC Zinc-Coated Steel
Material of Main Chassis	1.2mm SECC Zinc-Coated Steel (Japan Made)
Color of Front Bezel	Blue
Color of Main Chassis	Black
Front Connector	2x USB 3.0
Motherboard Size	12 x 9.6 (ATX, microATX, mini-ITX)
Cooling Fan	1x80mm
Optional Fan:	60mm x3 (bracket DD-FANGUARD-6 required)
Dimensions (WxHxD)	19.00" x 3.50" x 20.80" 482.6 mm x 88.9 mm x 528.3 mm
Notes	- low profile backplate option, P/N: DD-200-LP-PCI. - cross bar option for redundant power supplies, P/N: DD-200-R2U-BAR.

Download

There are no downloadable media for this product.

FAQ

There are no FAQ entries for this model.

Optional Accessories

	Model #	Description
	BPU-124V2-SS	Build-to-Order - 5.25" to 4x 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack
	BPU-126-SA	Special Order - 5.25" to 6x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack
	BPU-2535-SI	Build-to-Order - 3.5" to 2.5" SATA 6 Gbps HDD Hot-swap Rack
	DD-FAN60-Q	60mm Liquid State Bearing Fan
	DIY-RHF03	Build-to-Order - 3.5" to 5.25" Anti-Vibration Hard Drive Mounting Bracket
	RP-COMBO-SLIM	5.25" Optical Drive and Floppy Drive Cage Holder
	RP-COMBO-SLIM2535	2.5"/ 3.5" HDD & Slim Optical Drive to 5.25" Drive Bay Cage
	RP-FDD35	5.25" Drive Bay Bracket for 3.5" Devices
	RP-HDD2.5	2.5" to 3.5" Hard Drive Mounting Bracket
	RP-HDD25BC	2.5" HDD SSD Mounting Bracket for 3.5" Bay
	RP-HDD3.5	3.5" to 5.25" Hard Drive Mounting Bracket
	RP-HUB-SAUF	3.5" Combo Hub for USB2.0/ Firewire/ e-SATA
	RP-READER35	Build-to-Order - All-in-one USB 2.0 Card Reader
	T-25HD-SI	Build-to-Order - 2.5" SATA HDD SSD Slot Carrier
	T5F-SS	EOL - Trayless 5.25" to 3.5" SAS SATA HDD Anti-vibration Hot-swap Rack
	T5-SA	Build-to-Order - Trayless 5.25" to 3.5" SATA HDD Anti-vibration Hotswap Rack
	T-7M1-SATA	5.25" to 3.5" 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack
	T-7-SA	Rugged 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack
	TC-ISTORM8	3.5" to 5.25" Hard Drive Cooling Heat Sink
	TC-RAIL-20-D2	20" Sliding Rail Kit for D Storm 2U Chassis
	TC-RAIL-24-D2	24" Sliding Rail Kit for D Storm 2U Chassis
	TC-RAIL-26-D2	26" Sliding Rail Kit for D Storm 2U Chassis
	DD-200-LP-PCI	D Storm 2U Low Profile Backplate
	DD-200-SE-BLACK	2U Black Bezel for SE series
	DD-200-SE-BLUE	2U Blue Bezel for SE series
	DD-200-SE-RED	2U Red Bezel for SE series
	DD-200-SE-SILVER	2U Silver Bezel for SE series
	BPN-DE110SS	Trayless 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack
	BPU-124DE-SS	5.25" to 4x 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack
	T-G525-SS	Industrial 5.25" to 3.5" 2.5" SATA SAS 6 Gbps HDD SSD Hotswap Rack
	BPN-2535DE-SA	3.5" to 2x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack
	T-G35-SS	Industrial 3.5" to 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack
	BPN-DE110SS-WB	Trayless 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack with Wood Look Bezel
	BPN-124K-SA	Trayless 5.25" to 4x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack
	T-5K3525U-SA	Trayless 5.25" to 3.5" & 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack with USB 3.0
	T-5K225T-SA	Trayless 5.25" to Slim ODD and 2x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack
	T-5K35T-SA	Trayless 5.25" to Slim ODD and 3.5" SATA 6 Gbps HDD Hot-swap Anti-vibration Rack
	T-5K25TU-SA	Trayless 5.25" to Slim ODD and 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack with USB 3.0
	T-35K25-SA	Build-to-Order - Trayless 3.5" to 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack
