Models |
|
![](images/BPU-230SATA_front.png) BPU-230SATA 2x5.25" to 3x3.5" SAS/SATA 6.0 Gb/s Hot-Swap Cage
Single tray option
|
|
![](images/BPU-340SATA_front.png) BPU-340SATA 3x5.25" to 4x3.5" SAS/SATA 6.0 Gb/s Hot-Swap Cage
Single tray option
|
|
![](images/BPU-350SATA_front.png) BPU-350SATA 3x5.25" to 5x3.5" SAS/SATA 6.0 Gb/s Hot-Swap Cage
Single tray option
|
|
Dimensions (WxHxD) |
5.75" x 3.39" x 7.95" 146.1 mm x 86.1 mm x 201.9 mm |
5.75" x 4.96" x 7.95" 146.1 mm x 126.0 mm x 201.9 mm |
5.75" x 4.96" x 8.11" 146.1 mm x 126.0 mm x 206.0 mm |
|
Standard Drive Bays |
5.25" Drives: 2 3.5" Hotswap: 3 |
5.25" Drives: 3 3.5" Hotswap: 4 |
5.25" Drives: 3 3.5" Hotswap: 5 |
|
Hotswap HDD Type |
![](images/BPU-s_hdd.png) |
|
Indicators |
Power, HDD, fan, and high temperature |
|
Material of Handle |
Aluminum |
|
Material of Main Chassis |
Aluminum Design with Conductive Dissipation Grooves |
|
Material of Front Bezel |
Aluminum |
|
Color and Material of Front Bezel |
![](images/BPU-s_bezels.png) |
|
Color of Main Chassis |
Black |
|
Cooling Fan |
![](images/BPU-s_fan.png) |
|
Ordering Information (Part Number) |
Black Tray: BPU-230SATA-BLACK
Blue Tray: BPN-DE110SS-BLUE
Red Tray: BPU-230SATA-RED
Silver Tray: BPU-230SATA-SILVER
Lockable Tray: BPU-230SATA-BPL |
|
Black Tray: BPU-340SATA-BLACK
Blue Tray: BPU-340SATA-BLUE
Red Tray: BPU-340SATA-RED
Silver Tray: BPU-340SATA-SILVER
Lockable Tray: BPU-340SATA-BPL |
|
Black Tray: BPU-350SATA-BLACK
Blue Tray: BPN-DE340SS-BLUE
Red Tray: BPN-DE340SS-RED
Silver Tray: BPN-DE340SS-SILVER
Lockable Tray: BPU-230SATA-BPL |
|
Package Content |
![](images/BPU-230SATA_pkg.png) SATA Cable Included (3pcs) |
![](images/BPU-340SATA_pkg.png) SATA Cable Included (4pcs) |
![](images/BPU-350SATA_pkg.png) SATA Cable Included (5pcs) |
|
Download |
Data Sheet (PDF)
Product Drawing (PDF)
User's Manual (PDF)
AN-B Tray Type Hotswap cage |
Data Sheet (PDF)
Product Drawing (PDF)
User's Manual (PDF)
AN-B Tray Type Hotswap cage |
Data Sheet (PDF)
Product Drawing (PDF)
User's Manual (PDF)
AN-B Tray Type Hotswap cage |
