Specifications | Download | FAQ |
Optional Accessories | Compatible Power Supplies | Compatible Motherboards |
Back Panel | ![]() |
Model Number | D-406SE-50R8PD8 |
RoHS Compliance | Yes |
Form factor | 4 U |
Standard Drive Bays |
3.5" Drives: 2 3.5" Drive (internal): 2 5.25" Drives: 6 |
Indicators | Power, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 ) |
Switches | Power, Reset |
Supported PSU Type | PS2, Mini Redundant |
Expansion Slots | 7 |
Security | Front Bezel Key Lock |
Material of Front Bezel | Aluminum alloy |
Material of Handle | SECC Zinc-Coated Steel |
Material of Main Chassis | 1.2mm SECC Zinc-Coated Steel (Japan Made) |
Color of Front Bezel | Blue |
Color of Main Chassis | Black |
Front Connector | 2x USB 2.0 |
Air Filter | Removable & Washable |
Motherboard Size | 12 x 9.6 (ATX, microATX) |
Cooling Fan | 1x80mm |
Optional Fan: | 80mm x1 |
Ordering Information (Part Number) | Blue Bezel:D-406SE-50R8PD8 Black Bezel:D-406SE-BK-50R8PD8 Red Bezel:D-406SE-RD-50R8PD8 Silver Bezel:D-406SE-SL-50R8PD8 |
Dimensions (WxHxD) | 19.00" x 7.00" x 20.80" 482.6 mm x 177.8 mm x 528.3 mm |
There are no downloadable media for this product. |
There are no FAQ entries for this model. |
Model # | Description | |
![]() | BPU-124V2-SS | Build-to-Order - 5.25" to 4x 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack |
![]() | BPU-126-SA | Special Order - 5.25" to 6x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack |
![]() | BPU-230SATA | 2x 5.25" to 3x 3.5" 2.5" SAS SATA 6 Gbps HDD SSD Hot-swap Rack |
![]() | BPU-2535-SI | Build-to-Order - 3.5" to 2.5" SATA 6 Gbps HDD Hot-swap Rack |
![]() | BPU-340SATA | 3x 5.25" to 4x 3.5" 2.5" SAS SATA 6 Gbps HDD SSD Hot-swap Rack |
![]() | BPU-350SATA | 3x 5.25" to 5x 3.5" 2.5" SAS SATA 6 Gbps HDD SSD Hot-swap Rack |
![]() | DD-FAN80 | 80mm Ball Bearing Fan |
![]() | DIY-RHF03 | Build-to-Order - 3.5" to 5.25" Anti-Vibration Hard Drive Mounting Bracket |
![]() | RP-COMBO-SLIM | 5.25" Optical Drive and Floppy Drive Cage Holder |
![]() | RP-COMBO-SLIM2535 | 2.5"/ 3.5" HDD & Slim Optical Drive to 5.25" Drive Bay Cage |
![]() | RP-FDD35 | 5.25" Drive Bay Bracket for 3.5" Devices |
![]() | RP-HDD2.5 | 2.5" to 3.5" Hard Drive Mounting Bracket |
![]() | RP-HDD25BC | 2.5" HDD SSD Mounting Bracket for 3.5" Bay |
![]() | RP-HDD25P | 3.5" Drive Bay Bracket for 2x 2.5" SSDs |
![]() | RP-HDD3.5 | 3.5" to 5.25" Hard Drive Mounting Bracket |
![]() | RP-HUB-SAUF | 3.5" Combo Hub for USB2.0/ Firewire/ e-SATA |
![]() | RP-READER35 | Build-to-Order - All-in-one USB 2.0 Card Reader |
![]() | T-25HD-SI | Build-to-Order - 2.5" SATA HDD SSD Slot Carrier |
![]() | T5F-SS | EOL - Trayless 5.25" to 3.5" SAS SATA HDD Anti-vibration Hot-swap Rack |
![]() | T5-SA | Build-to-Order - Trayless 5.25" to 3.5" SATA HDD Anti-vibration Hotswap Rack |
![]() | T-7M1-SATA | 5.25" to 3.5" 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack |
![]() | T-7-SA | Rugged 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack |
![]() | TC-ISF08 | 8 Ports Fan Sensor Board |
![]() | TC-ISTORM7 | 2x5.25" to 3x3.5" Internal Mounting Cooling Kit with Removable Filter |
![]() | TC-ISTORM8 | 3.5" to 5.25" Hard Drive Cooling Heat Sink |
![]() | TC-RAIL-20 | 20" Sliding Rail Kit for Most Rackmount Chassis |
![]() | TC-RAIL-24 | 24" Sliding Rail Kit for Most Rackmount Chassis |
![]() | TC-RAIL-26 | 26" Sliding Rail Kit for Most Rackmount Chassis |
![]() | BPN-DE230SS | Trayless 2x5.25" to 3x 3.5" SAS SATA 6 Gbps HDD Hot-swap Rack |
![]() | BPN-DE340SS | Trayless 3x 5.25" to 4x 3.5" SAS SATA 6 Gbps HDD Hot-swap Rack |
![]() | RP-4HDD255F | EOL 4x 2.5" HDDs/SSDs to 5.25" Drive Bay Bracket |
![]() | RP-2HDD2535 | 5.25" Drive Bay Cage for 3.5" and 2.5" Hard Drives |
![]() | DD-400-DBLUE | D-400 BLUE DOOR |
![]() | DD-400-DRED | D-400 RED DOOR |
![]() | DD-400-DSILVER | D-400 SILVER DOOR |
![]() | DD-400-SE-BLACK | 4U Black Bezel for SE series |
![]() | DD-400-SE-BLUE | 4U Blue Bezel for SE series |
![]() | DD-400-SE-RED | 4U Red Bezel for SE series |
![]() | DD-400-SE-SILVER | 4U Silver Bezel for SE series |
![]() | BPN-DE110SS | Trayless 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack |
![]() | BPU-124DE-SS | 5.25" to 4x 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack |
![]() | T-G525-SS | Industrial 5.25" to 3.5" 2.5" SATA SAS 6 Gbps HDD SSD Hotswap Rack |
![]() | BPN-2535DE-SA | 3.5" to 2x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack |
![]() | T-G35-SS | Industrial 3.5" to 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack |
![]() | BPN-DE110SS-WB | Trayless 5.25" to 3.5" SATA SAS 6 Gbps HDD Hot-swap Rack with Wood Look Bezel |
![]() | BPN-DE230SS-WB | Trayless 2x 5.25" to 3x 3.5" SAS SATA 6 Gbps HDD Hot-swap Rack with Wood Look Bezel |
![]() | BPN-DE340SS-WB | Trayless 3x 5.25" to 4x 3.5" SAS SATA 6 Gbps HDD Hot-swap Rack with Wood Look Bezel |
![]() | BPN-124K-SA | Trayless 5.25" to 4x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack |
![]() | T-5K3525U-SA | Trayless 5.25" to 3.5" & 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack with USB 3.0 |
![]() | T-5K225T-SA | Trayless 5.25" to Slim ODD and 2x 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack |
![]() | T-5K35T-SA | Trayless 5.25" to Slim ODD and 3.5" SATA 6 Gbps HDD Hot-swap Anti-vibration Rack |
![]() | T-5K25TU-SA | Trayless 5.25" to Slim ODD and 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack with USB 3.0 |
![]() | T-35K25-SA | Build-to-Order - Trayless 3.5" to 2.5" SATA 6 Gbps HDD SSD Hot-swap Rack |
![]() | DD-FANBAR | Center Support Bar for D Storm 2U 3U 4U Chassis |
![]() | BPN-DE350SS | Trayless 3x 5.25" to 5x 3.5" SAS SATA 6 Gbps HDD Hot-swap Rack |
